BTR LS6 BEEHIVE SPRING - .560 LIFT - PACK OF 160 - SP011-160
BTR's .560" lift LS6-style valve springs gives you all of the performance of the venerable OEM LS6 valve spring (GM part # 12499224 or 12586484) at a fraction of the cost. These springs pair perfectly with our truck series camshafts and are also a great option for replacing worn out or broken springs in stock applications. Pair with OEM retainers or upgrade to titanium with our SR007-16 retainer set!
- 100 lbs @ 1.800” Installed pressure / height
- 285 lbs @ 1.240” Open pressure / height
- Coil bind @ 1.150”
NOTE - BTR does not recommend single wire conical or beehive springs with roller rockers due to the extra mass causing loss of valve train stability, or the use of a higher ratio rocker as it could possibly cause a coil bind issue. If you have a specific combination of valvetrain parts you are needing to use a roller rocker on, please call in to our sales team for clarification.
Features:
| BTR SKU | SP011-160 |
|---|---|
| Length | 12.000000 |
| Width | 8.000000 |
| Height | 2.000000 |
| Weight | 40.000000 |
| Brand | Brian Tooley Racing |
| Part Type | Valve Springs |
| Engine Type | Gen III/Gen IV LS |
| Spring Type | SINGLE |
